The model AC600 is featuring an industry leading 99% recovery efficiency for standard and hybrid vehicles and fully automatic function. The AC600 machine recover, recycle, evacuate, leak-test and recharge 1234yf with improved 99% efficiency. It has automatic refrigerant refill and oil drain/inject – putting A/C lubricant back into the system. AC600 also builtin thermal printer and oil capacities database is available for all passenger vehicles.
- Automatic recovery/recycling/recharge, walk away and return when complete
- Automatic discharging used oil/oil drain.
- Automatic vacuum helps get to the necessary vacuum level in any condition quickly
- Automatic new oil injection shows how much oil was removed from the system during service
- Automatic internal tank refill. No stopping to fill the internal tank during service
- Automatic air purge removes the potential of air accumulating in the internal tank
- Comprehensive A/C capacity database
- Support Auto Mode: One step to do automatic recovery, recycling, vacuum and recharge
- Tank filling with manual or pre-set value options
- Onboard electronic scales
- Built in thermal printer
- Tank installed internally
- Vacuum leak test to identify gross leaks in a system
- Flashing feature
- Separate POE and PAG oil injection, good for service both electric/hybrid car and regular car
| Model |
AC900 |
| Dimension |
Package in crate 720*670*1170mm (29”x26”x47”); Unpacked machine 630*560*1075mm (24”x22”46”) |
| Power supply |
AC110V±10％~60Hz |
| Compressor Power |
3/8 HP |
| Vacuum Pump Capacity |
120L(32Gal)/min |
| Evacuation time selection |
2-240min |
| Vacuum leak test time selection |
0-30min |
| Electronic oil injection |
3 separate vessels, 250ml capacity for PAG /POE/UV, high transparency |
| Used oil vessel |
400ml capacity, high transparency |
| Refrigerant charging speed |
1Kg/Min |
| High capacity spin on filter-dryer |
600ml capacity |
| Accuracy of refrigerant cylinder load cell |
±10g |
| Accuracy of oil containers load cells |
±3g (For better oil injection accuracy, ±1g, please order optional function of individual load cell for each oil vessel) |
| Refrigerant cylinder |
10KG, with heater |
| Machine maximum working pressure |
20bar |
| Display |
7’’ touch screen, powered by android platform |
| Gauges |
High side -1bar~30bar, Low side -1bar~16bar |
| Digitally displayed cylinder pressure and temperature |
| Vehicle A/C database included, with additional user database input |
| Thermal printer |
| Electronically controlled air purge |
| Electronically monitoring and displaying system service intervals |
| Flush function |
Unidirectional or bi-directional, time selection: 10-60 min |
| Individual load cell for each oil vessel, to make higher accuracy of oil injection |
±1g |
![]()
